Standard Hard drive head (for external parking heads) swap replacement repair tool for Seagate, Western Digital, Samsung, Hitachi, Fujitsu, Toshiba HDDs.
Starting in 2025, we have upgraded the tool set. Compared to the previous version of the set, 21 new models have been added. In the future, we will continue to develop and make our tool suite support more models of hard drives.
Tool for: HDD heads swap replacement;
Suit for HDDs: Seagate, WD, Samsung, Hitachi, Fujitsu, Toshiba, etc.
Suit for hard drive form factors: 2.5" & 3.5";
Category: Hard drive repair tools - Hard drive head repair tool;
HDD head combs are a safe and easy way to change heads on hard disk drives. These tools ensure a non-contact HDD head replacement.
Difference between HDD Head Combs Tool A & B
- Standard HDD Head Combs Tool A: HDD Head inside parking
- Standard HDD Head Combs Tool B: HDD Head outside parking
We strongly recommend that you also purchase another set of heads swap tool: Standard HDD Head Combs Tool (A). These two sets of tools are complementary. With these two sets of tools, you can safely replace most of the hard disks' heads.
Seagate Series
WD Series
Seagate Series (STH81)
WD Series (W3-9)
Western Digital Hard Drive Head Combs: (supported HDD models)
W1S: Western Digital 2.5″ HDDs, 2 platters For Western Digital SMR Palmer HDD 800066, 800069, 1 platter 2 heads MQ04ABF100;
W2S：Western Digital 2.5″ HDDs, 2 platters for Western Digital 800065, 800067, 810003 charger HDDs;
W2-2: Western Digital 2.5″ HDDs, 2 platters;
W2-3: Western Digital 2.5″ HDDs, 3 platters;
W2-4: Western Digital 2.5″ HDDs, 4 platters;
W2-5: Western Digital new 2.5″ HDDs of WD40NMZW, WD30NMVW 5 platters 10 heads;
W3-2: Western Digital 3.5″ HDDs, 2 platters;
W3-3: Western Digital 3.5″ HDDs, 3 platters, Type 2;
W3-4: Western Digital 3.5″ HDDs, 4 platters;
W3-5: Western Digital 6TB HDD head comb, 3.5″ HDDs, 5 platters 10 heads;
W3-1 3: Western Digital 3.5″ HDDs, 3 platters, Type 1;
W3S：example upported models-WD60PURX-64T0ZY0; WD40EJRX-89AKWY0，2-3 platters;
W3S1: 1 platter 2TB WD20EZAZ;
W3S3: 2-3 platters 4TB or 6TB WD40EZAZ WD60EDAZ R/N:810011;
W35S: Western Digital 3.5″ HDDs, 5 platters WD4002FYYZ;
W3-8: Western Digital helium HDD of 12TB, 8 platters WD120EDAZ;
W3-9: Western Digital helium HDD of DC HC550 16TB, 9 platters;
WS2: Upgraded version of W2S for 800065, 800067;
Seagate Hard Drive Head Combs: (supported HDD models)
ST2-1: Seagate 2.5″ HDDs, 1 platters;
ST2-2: Seagate 2.5″ HDDs, 2 platters;
ST2-3: Seagate 2.5″ HDDs, 3 platters, ST200LM005, ST1000LM041 (2025 new);
ST2-4: Seagate 2.5″ HDDs, 4 platters;
ST2-5: Seagate 4TB laptop HDDs, ST4000LM016, 5 platters, 10 heads;
ST331: Seagate 3.5″ HDDs with 1 platters and 2 heads, 1TB ST1000DM003, 2TB ST2000DM005 (2025 new);
ST332: Seagate 3.5″ HDDs, 2 platters;
ST334: Seagate 3.5″ HDDs, 4 platters;
ST313: Seagate 3.5″ HDDs, 3 platters, Type 1;
ST323: Seagate 3.5″ HDDs, 3 platters, Type 2;
STES53: Seagate enterprise 3.5″ HDDs, 5 platters supported and the ES.3 1-3T HDDs are tested.;
ST3-6: Seagate 3.5″ 8TB HDDs with 6 platters and 12 heads;
ST3-4: Seagate ST8000NM0178, 8TB, 4 platters;;
ST3-5: Seagate ST4000NM0035, 4TB, 5 platters;;
SST21: Seagate SAS 2.5″ HDDs, 1 platter;
SST22: Seagate SAS 2.5″ HDDs, 2 platters;
SST23: Seagate SAS 2.5″ HDDs, 3 platters;
SST24: Seagate SAS HDDs, ST1800MM0129 1.8T, ST2400MM0129 2.4T;
STH81: Seagate 3.5″ 10TB HDDs with 8 platters and 16 heads ST10000NM0478 (ST Helium HDD);
STH82: Seagate 3.5″ 12TB HDDs with 8 platters and 16 heads, ST12000NM0007 (ST Helium HDD);
STH9: Seagate 3.5″ 14TB and 16TB HDDs with 9 platters and 18 heads, ST14000NM002G, ST16000NM001G (ST Helium HDD);
ST5E: Seagate 3.5″ 8TB HDDs with 5 platters and 10 heads, ST80000NM000A (2025 new);
ST6E: Seagate 3.5″ 8TB HDDs with 6 platters and 12 heads, ST8000NM0055 (2025 new);
Hitachi(HGST) Hard Drive Head Combs:
H2-1: 2.5″ Hitachi HDDs, 1 platter;
H2-2: 2.5″ Hitachi HDDs, 2 platters;
HUS22: 2.5″ Hitachi SAS HDDs, 2 platters;
H312: 3.5″ Hitachi HDDs, 2 platters;
H313: 3.5″ Hitachi HDDs, 3 platters;
H3-5: 3.5″ Hitachi HDDs, 5 platters;
Toshiba Hard Drive Head Combs:
T2-1: for laptop toshiba HDDs with 1 platter (please note the existing T22 is used for 1-platter toshiba laptop HDDs for many cases);
T2-2: Toshiba 2.5″ HDDs, 2 platters;
T2-3: Toshiba 2.5″ HDDs, 3 platters;
T2-4: Toshiba new 2.5″ HDDs with 4 platters and 8 heads;
T312:Toshiba new 3.5″ HDDs with 1-2 platters and1-4 heads;
T3-3: Toshiba new 3.5″ HDDs with 3 platters and 5-6 heads;
T3-7: Toshiba new 3.5″ HDDs with7 platters and 10-14 heads, MG06ACA800E, 8TB;
Fujitsu Hard Drive Head Combs:
FU22: Fujitsu 2.5″ HDDs, 2 platters;
FUS22: Fujitsu SAS 2.5″ HDDs, 2 platters, 4 heads (S26361-F4006-L114);
Samsung Hard Drive Head Combs:
SX22: Samsung 2.5″ HDDS, 2 platters;
SX23: Seagate Samsung 2.5″ HDDs, 3 platters, ST2000lm003 2TB laptop drive;
Note: Before you can use this tool very well, you need to have some experience of head replacement or have used familiar head replacement products or you need more practice on the toolkit, you should have clean room environment or at least one qualified clean bench. We are not responsible for any damage done directly or indirectly due to improper use of tools.
